|Filename||File Type||File Size|
|Design into 3D_ Box with Lid - top||c2d||88.72kB|
|Design into 3D_ Box with Lid - bottom||c2d||156.48kB|
|Design into 3D_ Box with Lid - sides||c2d||1.82MB|
|Design into 3D_ Box with Lid - front-back||c2d||1.60MB|
Uses blind miter hidden box joint joinery and requires a 1/8" diameter 90 degree V endmill (#390) and a #282 --- instead of a #102, a 1/8" downcut endmill will minimize the need for post-processing.
Set the Z origin 8.35mm above the surface of the wasteboard.
It will be necessary to square up the opening on the front to admit the lid.
